ES-295
Verification of Newton's law of cooling (C.R)
Physics Laboratory Experimental Set-Ups (ES Series)
About a Product
OBJECT :-
To verify Newton’s law of cooling by drawing a cooling curve for the liquid.
Technical Specification
FEATURES :-
The complete Experimental Set-up consists of the followings :
01 NEWTON’S LAW OF COOLING APPARATUS : Joule’s Calorimeter consisting of Copper Calorimeter fitted in teakwood polished case with bakelite top having holes for thermometer & stirrer, two terminals connected to a coil of wire.
02 THERMOMETER : 110°C x ½.
03 Battery Eliminator OMEGA TYPE BE-5/3. 0-5V D.C. at 3A, continuously variable regulated and short circuit protected
04 DIGITAL STOP CLOCK : With START/STOP operation by means of toggle switch & RESET by a push button switch.
OMEGA TYPE DSC-602 It has a range of 999.9 seconds with resolution of 0.1 seconds and accuracy of ±0.01% (Quartz controlled).
Display is thorough 4 no’s of 12.5mm bright Seven Segment Displays and working voltage of the unit is 230V± 10% 50Hz.
